XMLK200P2C23TQ - Electronic pressure sensors, Pressure sensors XM - Telemecanique - Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...200 PSI, 1/4NPT, 4...20 mA, DIN, set of 25 - Telemecanique - 0
XMLK200P2C23TQ - Electronic pressure sensors, Pressure sensors XM - Telemecanique - Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...200 PSI, 1/4NPT, 4...20 mA, DIN, set of 25 - Telemecanique - 0

XMLK200P2C23TQ – Telemecanique

Tellitav
84,69 € KM-ta
105,01 € KM-ga
Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...200 PSI, 1/4NPT, 4...20 mA, DIN, set of 25 - Telemecanique
 Korvis
105,01 €
Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...200 PSI, 1/4NPT, 4...20 mA, DIN, set of 25. This product is compatible with XZCC12FCM40B, XZCC12FDM40B, XZCP1141L2
SPETSIFIKATSIOONID
Main
Fluid connection type 1/4" - 18 NPT (male)
controlled fluid Air (0-80 °C), fresh water (0-80 °C)
Type of packing Group
pressure sensor name XMLK
pressure sensor type Pressure transmitter
Complementary
Accuracy 0.1 % of the measuring range
local display Without
Product certifications CSA C22-2 No 14UL 508RCM
Product or component type Electronic pressure sensors
[us] rated supply voltage 24 V DC SELV (voltage limits: 8-33 V)
Analogue output function 4...20 mA, 2-wire
Current consumption 20 mA
nema degree of protection NEMA 4
Quantity per set Set of 25
Drift of the sensitivity +/- 0,04 % of measuring range/°K
Drift of the zero point +/- 0,03 % of measuring range/°K
Electrical circuit type Control circuit
measurement accuracy +/- 1 % de la plage de mesure
Operating position Any position
repeat accuracy +/- 1 % de la plage de mesure
Materials in contact with fluid Ceramicstainless steel type AISI 303nitrile (NBR)
electrical connection 1 male connector EN 175301-803-A (ex DIN43650) 4 pins
Shock resistance 25 gn for 11 ms conforming to IEC 60068-2-27
Response time on output < 5 ms
Type of output signal Analogue
Protection type Load short-circuitreverse polarity
Environment
ip degree of protection IP65 conforming to IEC 60529
Range of product Telemecanique Pressure sensors XM
electromagnetic compatibility Electrostatic discharge immunity test conforming to IEC 61000-4-2 8 kV air, 6 kV contact, susceptibility to electromagnetic fields conforming to IEC 61000-4-3 10 V/m 80...1000 MHz, electrical fast transient/burst immunity test conforming to IEC 61000-4-4 2 kV, 1.2/50 µs shock waves immunity test conforming to IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm, radiated RF fields conforming to IEC 61000-4-6 10 V 0.15...80 MHz, immunity to magnetic fields conforming to IEC 61000-4-8 30 A/m 50 Hz
standards CEIEC 61326-2-3
vibration resistance 20 gn (f = 9-2000 Hz) conforming to IEC 60068-2-6
protective treatment TC
