XCSM37F0L1S25 - Telemecanique ⚡

XCSM37F0L1S25 - Safety limit switch, Telemecanique Safety switches XCS - Telemecanique - Safety limit switch, Telemecanique Safety switches XCS, XCSM, metal, rotary lever, 2 NC + 1 NO, cable 1 m - Telemecanique - 0

Tellimisel

XCSM37F0L1S25 – Telemecanique

43,95 € KM-ta

54,50 € KM-ga

Safety limit switch, Telemecanique Safety switches XCS, XCSM, metal, rotary lever, 2 NC + 1 NO, cable 1 m - Telemecanique

Korvis

54,50 €

Safety limit switch, Telemecanique Safety switches XCS, XCSM, metal, rotary lever, 2 NC + 1 NO, cable 1 m

SPETSIFIKATSIOONID

Main

design Miniature

Protection technology Plastic protective cover, secured by 5-lobe socket head safety screw

component name XCSM

head type Rotary head

Complementary

cable composition 7 x 0.5 mm²

Product certifications CSAUL

Product or component type Safety limit switch

contact operation Slow-break, break before make

Contacts type and composition 1 NC + 1 NC + 1 NO

Electrical shock protection class Class I, class I conforming to IEC 61140

Fixing mode By the body

safety reliability data B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear

body material Zamak

Material Metal

Type of operator Steel roller lever

Ik degree of protection IK06 conforming to IEC 62262

contact code designation B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to IEC 60947-5-1, B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to IEC 60947-5-1, R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to IEC 60947-5-1 appendix A

head material Zamak

repeat accuracy 0.05 mm on the tripping points

Positive opening With NC contact

electrical connection Pre-cabled

Switch actuation By 30° cam

Type of approach Lateral approach

Shock resistance 25 gn for 18 ms conforming to IEC 60068-2-27

Resistance across terminals 25 MOhm conforming to IEC 60255-7 category 3

Safety level Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508

Environment

ip degree of protection IP66 conforming to IEC 60529, IP67 conforming to IEC 60529, IP68 conforming to IEC 60529

Range of product Telemecanique Safety switches XCS

standards CSA C22.2 No 14UL 508IEC 60947-5-1EN 1088IEC 60204-1

vibration resistance 25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6

protective treatment TC
